IntroductionHikelok subsea filters include dual-disc line and cup-type. Dual-disc line filters are utilized in numerous industrial,chemical processing, aerospace, nuclear and other applications. With the dual-disc design, large contaminant particles are trapped by the upstream filter element before they can reach and clog the smaller micron-size downstream element.And high flow cup-type line filters are recommended in medium pressure systems requiring both high flow rates and maximum filter surface area. Widely used in the industrial and chemical processing fields, the cup design offers as much as six times the effective filter area as compared to disc-type units.
FeaturesMaximum working pressure up to 20,000 psig (1379 bar)Working temperature from -60℉ to 660℉ (-50℃ to 350℃)Available size MPF 1/4, 3/8, 9/16, 3/4 and 1 inchMaterials: 316 Stainless Steel: Body, covers and gland nutsFilters: 316L Stainless SteelDual-disc filter flements: downstream/upstream micron size 35/65 is standard. 5/10 or 10/35 also available when specified. Other element combinations available on special orderHigh flow cup-type filter elements: Stainless Steel sintered cup.Standard elements available in choice of 5, 35 or 65 micron sizes
AdvantagesThe filter elements can be quickly and easily replacedPressure differential not to exceed 1,000 psi (69 bar) in a flowing conditionCup-type line filters are recommended in low pressure systems requiring both high flow rates and maximum filter surface areaThe cup design offers as much as six times the effective filter area as compared to disc-type units
More OptionsOptional high flow cup-type and dual-disc line filters
